Tornado Lift Machines

Automatic Storage Machines are computer-controlled storage and transfer systems that can significantly improve the efficiency of product storage and picking. These machines are easy to integrate with a Company’s existing Warehouse Management System (WMS), but they can also be used as a standalone system. The site and operating environment determines the system’s size and composition.

alternatively call
0113 270 4872


Tornado vertical Lift storage machines offer:

  • More goods can be fitted into the same space – up to a 70% increase in horizontal capacity.
  • Efficient picking – up to 65% reduction in picking times.
  • Ergonomic operation – automatic delivery of trays to an optimal working level.
  • Prevention of unauthorized use – reduction of losses.
  • Easy, paperless order processing.
  • The Windows-based PC control system allows easy integration with many types of WMS.
  • Minimization of picking errors.
  • Can transfer goods between floors like a lift.
  • The latest technology on the market.

Tornado vertical storage machine dimensions and statistics:

  • Tray width (internal): 1250-4000 mm
  • Tray depth (internal): 520, 620, 720, 820 and 1220 mm (other dimensions on request)
  • Tray load capacity: 500 kg maximum
  • Load height: 850 mm maximum
  • Total load capacity: 40 000 kg maximum
  • Total height: 15 m maximum
  • Electrical connection: 400 VAC
  • Motor output: 5.5 kW
